Crashrail WG150
WG 150 Wall protection system for medical centers
A bump for medical centers is an ideal choice for protecting walls from wear and tear of interior decoration. The wall protection system with a vinyl profile dampens the impact from strollers and wheelchairs due to a double rubber insert. Decorative elements offer a modern design solution.
Accessories:
- Vinyl profile - 2 mm
- Aluminum Profile
- TEP rubber insert
- WG013 Plug Left \ Right
- WG014 External angle
Installation:
- Installation is carried out locally, taking into account the layout of the room, the size of accessories and their configuration;
- We attach the plugs and corner adapters to the aluminum profile using self-tapping screws;
- We mount the bump on the wall using a solid aluminum profile with fixing elements with an interval of 600 - 800 mm;
- We insert a shock-absorbing rubber insert;
- Snap the vinyl profile on top.
Note:In this model, there are two shock-absorbing inserts and does not have such a transitional element as an inner corner.
| Model | The length of the profile | Profile width | The thickness of the profile | The number of shock absorbing inserts | Plug left | Plug right | The outer corner | Internal corner | The number of possible colors |
|---|---|---|---|---|---|---|---|---|---|
| CR 50 | 4 m | 50 mm | 20 mm | - | WG016 | WG016 | - | - | 5 colors* |
| DC 150 | 4 m | 150 mm | 30 mm | 1 | DC013 | DC013 | DC014 | - | 5 colors* |
| DC 200 | 4 m | 200 mm | 30 mm | 1 | DC001 | DC001 | DC003 | - | 5 colors* |
| WG 100 | 4 m | 100 mm | 20 mm | 1 | WG020 | WG020 | - | - | 5 colors* |
| WG 150 | 4 m | 150 mm | 20 mm | 2 | WG020 | WG020 | WG014 | - | 5 colors* |
| WG 201 | 4 m | 200 mm | 20 mm | 3 | WG030 | WG030 | - | - | 5 colors* |
| WG 200 | 4 m | 200 mm | 20 mm | 2 | WG001 | WG002 | WG003 | WG004 | 5 colors* |
* all color palette consists of 32 colors and is available at the order of 300 m.p. each item
